| معلومات عامة |
|
| نوع المنتج |
اللوحة الام للألعاب |
| العلامة التجارية |
ASUS TUF |
| اللون |
اسود |
| الموديل |
H670-PRO |
| المواصفات التقنية |
|
| CPU |
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
|
| Chipset |
H670 |
| الذاكرة |
4x DIMM, Max. 128GB, DDR4 5333(OC) |
| الرسومات |
Supports max. 4K@60Hz as specified in DisplayPort 1.4, Supports 4K@60Hz as specified in HDMI 2.1 |
| Expansion Slots |
Intel® 12th Gen Processors,1x PCIe 5.0 x16 slot Intel® H670 Chipset 1x PCIe 3.0 x16 slot (supports x4 mode), 2x PCIe 3.0 x1 slots |
| التخزين |
Supports 4 x M.2 slots and 4 x SATA 6Gb/s ports |
| LAN |
1x Intel® 2.5Gb Ethernet, TUF LANGuard |
| USB |
Rear USB: Total 7 ports, Front USB: Total 7 ports |
| Form Factor |
microATX |
| منافذ I/O الخلفية |
1x USB 3.2 Gen 2x2 port (1 x USB Type-C),2x USB 3.2 Gen 2 ports (2 x Type-A),4x USB 3.2 Gen 1 ports (4 x Type-A ),1x DisplayPort,1x HDMI port,1x Wi-Fi Module,1x Intel 2.5Gb Ethernet port,1x Intel 2.5Gb Ethernet port,5x Audio jacks,1x Optical S/PDIF out por
|
| نظام التشغيل |
ويندوز 10 64 بت, ويندوز 11 64بت |
| سهولة الادارة |
WOL by PXE, PME |
| BIOS |
192 (128+64) Mb Flash ROM, UEFI AMI BIOS |
