| معلومات عامة |
|
| نوع المنتج |
اللوحة الام |
| العلامة التجارية |
ASUS Prime |
| اللون |
اسود |
| الموديل |
B460M-A |
| المواصفات التقنية |
|
| CPU |
Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold and Celeron Processors, Supports Intel 14 nm CPU
|
| Chipset |
Intel B460 |
| الذاكرة |
4x DIMM, Max.128GB, DDR4 |
| الرسومات |
Integrated Graphics Processor- Intel UHD Graphics support,1x DisplayPort 1.4,1x HDMI 1.4b,1x DVI-D |
| Expansion Slots |
Intel 10th Gen Processors:1x PCIe 3.0/2.0 x16 (x16 mode),Intel B460 Chipset2x PCIe 3.0/2.0 x1 |
| التخزين |
Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports |
| LAN |
Realtek RTL8111H, 1 x Gigabit LAN Controller(s), support LANGuard |
| USB |
Rear USB: Total 6 ports, Front USB: Total 6 ports |
| Form Factor |
microATX |
| منافذ I/O الخلفية |
1x PS/2 keyboard/mouse combo port(s),1x DVI-D,1x DisplayPort,1x HDMI,1x LAN (RJ45) port(s),4x USB 3.2 Gen 1 Type-A,2x USB 2.0,3x Audio jack(s)
|
| نظام التشغيل |
ويندوز 10 64بت |
| سهولة الادارة |
WOL by PXE, PME |
| BIOS |
128Mb Flash ROM, UEFI AMI BIOS |
